G1

402.100

16 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 130°

cell depth: 5, 10, 15, 20, 25, 30, 35, 40 µm,

vol: 0.1, 0.5, 1.0, 1.7, 2.8, 4.1, 6.6, 8.8 ml/m²

40 l/cm (100 l/inch); screen angle 53°; stylus 130°

cell depth: 45, 50, 55, 60, 65, 70, 75, 80 µm,

vol: 6.1, 8.0, 10,7, 13.1, 15.6, 19.3, 20.7, 23.3 ml/m²

402.101

4 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 120°

cell depth: 30, 35, 40, 45 µm,

volume: 4.3, 6.4, 8.6, 11.4 ml/m²

402.103

4 engravings

40 l/cm (100 l/inch); screen angle 53°; stylus 120°

cell depth: 65, 70, 75, 80 µm,

volume: 15.6, 19.2, 19.7, 23.4 ml/m²

402.104

1 engraving

54 l/cm (135 l/inch); screen angle 53°; stylus 130°;

cell depth: 50 µm,

volume: 14.5 ml/m²

402.105

4 engravings

40 l/cm (100 l/inch); screen angle 53°; stylus 130°

cell depth: 30, 35, 40, 45 µm,

volume: 2.0, 3.2, 4.6, 6.0 ml/m²

402.106

1 engraving

60 l/cm (150 l/inch); screen angle 53°; stylus 120°;

cell depth: 60 µm,

volume: 19.5 ml/m²

402.107

1 engraving

40 l/cm (100 l/inch); screen angle 53°; stylus 120°;

cell depth: 90 µm,

volume: 24.9 ml/m²

402.108

1 engraving

70 l/cm (175 l/inch); screen angle 53°; stylus 120°;

cell depth: 50 µm,

volume: 13.5 ml/m²

402.109

11 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 120°

cell depth 48, 46, 44, 42, 38, 34, 30, 22, 18, 14 µm,

wedge cell depth 48 to 0 µm

402.110

11 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 140°

cell depth 33, 31, 30, 29, 26, 24, 20, 17, 14, 11 µm,

wedge cell depth 33 to 0 µm

402.111

1 engraving

48 l/cm (120 l/inch); screen angle 53°; stylus 120°;

cell depth 80 µm

402.112

1 engraving

54 l/cm (135 l/inch); screen angle 53°; stylus 130°;

cell depth 55 µm

402.116

2 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 120°;

cell depth 44, 38 µm

402.118

11 engravings

60 l/cm (150 l/inch); screen angle 53°; stylus 120°

cell depth 62, 60, 55, 51, 48, 43, 40, 34, 27, 24 µm,

wedge cell depth 62 to 0 µm

402.119

1 engraving

60 l/cm (150 l/inch); screen angle 53°; stylus 130°;

cell depth: 50 µm,

volume: 16.5 ml/m²

G1-5

402.150.433

1 engraving

70 l/cm (175 l/inch); screen angle 53°; stylus 120°,

cell depth: 50 µm,

volume: 13.5 ml/m²

402.151.433

4 engravings

40 l/cm (100 l/inch); screen angle 53°; stylus 120°,

cell depth: 65, 70, 75, 80 µm,

volume: 14, 17, 20, 25 ml/m²

402.152.433

11 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 120°

cell depth 48, 46, 44, 42, 38, 34, 30, 22, 18, 14 µm,

wedge cell depth 48 to 0 µm

402.153.433

11 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 140°

cell depth 33, 31, 30, 29, 26, 24, 20, 17, 14, 11 µm,

wedge cell depth 33 to 0 µm

402.154.433

4 engravings

70 l/cm (175 l/inch); screen angle 53°; stylus 140°

cell depth: 15, 20, 25, 30 µm,
